Details
The Instinct Powerplay SL Alloy is a lightweight marvel that packs a punch. With the new Dyname S4 Lite drive system, this bike rides like a trail bike while giving you the power to explore further. Thanks to its adjustable geometry, refined suspension kinematics, and MX compatibility, the Alloy Instinct Powerplay SL offers bold levels of playfulness and agility, lap after lap... after lap.
Wheel size
RIDE-9/4 POSITION
Specs
Frame | FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry | 145mm Travel | FORM™ Alloy Rear Triangle |
---|---|
Fork | RockShox Psylo Gold RC 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset |
Headset | FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Rear Shock | SM-XL: RockShox Deluxe Select+ | 230x57.5mm | XS: RockShox Deluxe Select+ | 210x52.5mm |
Rims/Wheels | WTB ST i30 TCS 2.0 | 28H | Tubeless Set Up | Sealant Incl |
Hubs | Front: Shimano TC500 | 15mm Boost, Rear: Shimano TC500 Boost 148mm |
Tires | Maxxis Minion DHF 2.5 WT EXO Tubeless Ready | Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready | Tubeless Set Up | Sealant Incl |
Crankset | Rocky Mountain Microdrive 2PC | Race Face 34T SHI 12 Ring | 24mm Spindle | Crank Length: 165mm |
Bottom Bracket | Rocky Mountain Sealed - Shimano Compatible |
Chain | Shimano M6100 |
Rear Derailleur | Shimano Deore 12spd |
Rear Cogs | Shimano Deore 10-51T 12spd |
Shifters | Shimano Deore 12spd |
Handlebars | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
Tape/Grips | ODI Elite Pro Lock On |
Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm |
Brakes | Shimano MT4120 4 Piston | Resin Pads |
Saddle | WTB Volt Race 142 | Cromoly rails |
Seat Post | X Fusion Manic Composite 30.9mm |XS - SM = 125mm | MD = 150mm | LG = 170mm | XL = 200mm |
Motor | Dyname S4 Lite Mountain Bike Drive | 250w Nominal Power | 550w Max Power | 65Nm |
Battery | 480 Wh Removable Integrated Li-Ion |
Weight | 47.08lbs |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
White/Grey / X-Small (27.5) | 770416001723 | B0415XS2 |
White/Grey / Small (29) | 770416001686 | B0415SM2 |
White/Grey / Medium (29) | 770416001662 | B0415MD2 |
White/Grey / Large (29) | 770416001648 | B0415LG2 |
White/Grey / X-Large (29) | 770416001709 | B0415XL2 |
