Details
The Instinct has always been the benchmark for those in search of a do-it-all quiver-killer. Designed to thrive on technical trails, but still allows you to push the distance and crush the climbs. We’ve updated the frame features, geometry, and suspension kinematics to make sure you feel confident on the up’s, down’s, and everything in between. Trust your Instinct.
What's New?
Refined geometry
We’ve increased the reach, made the seat tube angle steeper, lengthened the chainstays.
Total adjustability
Designed with adjustable frame features to suit all riders and riding styles. This is our most versatile platform.
Size-specific tune
Each frame size is tuned for small-bump compliance, mid-stroke support, and end-stroke progressiveness. Each framesize also features custom shock tunes based on real world field testing.
Reach adjust headset
Fine tune your ride with center, +/- 5mm offset options.
RIDE-4™ adjustment system
Allows riders to quickly fine-tune their geometry and suspension with a single Allen key.
Generous space for long dropper posts
Shorter seat tube lengths for increased dropper post fitment.
Storage included
The new PenaltyBox™ 2.0 downtube storage (carbon models only) includes generous capacity, custom tool wrap and our rock-solid hinged door system that doubles down as a water bottle mount and built-in concealed AirTag/Tile compartment.
Fully enclosed internal routing
Allows for easy cable and hose installations, with thoughtful consideration for moto-style brake setups.
Specs
Frame | SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. SMOOTHWALL™ Carbon Rear Triangle |
---|---|
Fork | Marzocchi Z2 Float EVOL Rail 150mm | 44mm Offset |
Headset | FSA Orbit NO.85 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Durable Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
Rear Shock | Fox Float DPS Performance | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm |
Rims/Wheels | WTB ST i30 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl |
Hubs | Front Hub:Shimano TC500 | 15x110m | 28H Rear Hub:Shimano TC500 Boost 148mm | 28H |
Spokes | 2.0 Stainless |
Tires | F: Maxxis Dissector 2.4 WT EXO Tubeless Ready // R: Maxxis Dissector 2.4 WT EXO Tubeless Ready |
Crankset | Shimano Deore | 32T | 24mm Spindle | Crankarm Length: XS - SM = 165mm | MD - XL = 170mm |
Bottom Bracket | Shimano SM-BBMT500 |
Chain | Shimano M6100 |
Rear Derailleur | Shimano Deore 12spd |
Rear Cogs | Shimano Deore 10-51T 12spd |
Shifters | Shimano Deore 12spd |
Handlebars | Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
Tape/Grips | Rocky Mountain Lock On Light |
Stem | Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm |
Brakes | Shimano MT4120 4 Piston | Resin Pads |
Saddle | WTB Volt Race 142 |
Seat Post | X Fusion Manic Composite 30.9mm | XS = 125mm | SM = 150mm | MD - LG = 170mm | XL = 200mm |
* Subject to change without notice.
